4G Module L860-GL FDD-LTE TDD-LTE Cat16 4G Card SPS#L27188-001 4G Card For HP laptop computer

L860-GL module Specs:

Observe:not for Thinkpad laptop computer

* Chipset: XMM7560

* LTE FDD:LTE FDD: Band 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 21, 25, 26, 28, 29, 30, 32, 66

* LTE TDD: B38/39/40/41/42

* UMTS: Band 1, 2, 4, 5, 8

* Kind issue: M.2 bundle

* Dimensions: 30.0*42.0*2.3 mm

* DL 5CA on 4 bands, DL 256QAM assist

* DL-MIMO: 2*2, 4*2, 4*4

* DL 4×4 MIMO: Band 1,2,3,4,7,30,40,41NB, 66

* LAA(Band 46)

* Built-in GNSS

* eSIM interface assist

* Working Voltage: 3.135V~4.4V, Typical 3.3V

* Working Temperature: -10~+55°C

* Storage Temperature: -40~+85°C

* AT Command Set: 3GPP TS 27.007 and 27.005, proprietary FIBOCOM AT instructions

* TX Energy:
– FDD& TDD LTE: 23dBm
– WCDMA: 23.5dBm

* RX Sensitivity: FDD& TDD LTE: -98dBm~102dBm

* Knowledge
– FDD& TDD LTE: 1Gbps DL(Cat 16), 150Mbps
– UL(Cat 13, 2CA on intra bands)
– UMTS/HSPA+: 42Mbps DL(Cat 24), 11.5Mbps
– UL(Cat 7)

* Interface
– USIM: 3V/1.8V
– PCIe
– BodySar

* Driver: Home windows 10 and Linux

Bundle embrace: 1* Card
