DSLRKIT 9 Ports 8 PoE Package (Swap + PoE Splitter) 18V-55V to 12V DC Buck converter

9 Ports 8 PoE Package (Swap + PoE Splitter)
Enter DC18V~55V energy provide, Output DC12V 1.3A
(Energy provide not included)

It is a low-cost and extremely dependable POE Package which is appropriate for all IP Cameras and IP telephone with 12V DC port and RJ45 community Port,together with Hikvision,DAHUA and different IP Digital camera manufacturers,regardless of supported 802.3af PoE Units or unsupported None-POE gadgets,
your system will need to have 12V DC port and RJ45 community Port are required situation, and the facility doesn’t exceed 15Watt(12v1.3a).

permitting the utmost cable size as much as 100 meters. Meantime the enter voltage has an excellent tolerance to DC18V~55V.

The PoE equipment Consists of an 9-port 8PoE 10/100Mbps-T Ethernet passive (unsolicited) PoE swap and 8pcs PoE splitters with DC buck to energy non-PoE gadgets. Please seek advice from the next images for utilization:

This equipment doesn’t embody an influence adapter. You need to use any energy provide between DC18V and 55V to attach it, however take note of the facility output polarity [inside positive (+), outside negative (-)],the facility enter socket on the swap needs to be appropriate for DC Port of dimension 5.5×2.1mm. and whether or not the output energy is sufficient for IP CAMERAS to make use of.

The POE splitter of this equipment integrates an 18V~60V DC Buck converter,plus the broad voltage passive POE swap is able to inputting DC12V~55V,so DC18V~55V energy adapter is allowed to energy the POE swap of this equipment,if situation is permitted,we advocate inputting greater voltage(DC48V~55V)to scale back energy loss within the community cable, thereby permitting longer community cable or enhancing the facility provide surroundings of the system,particularly the community cable is extraordinarily lengthy.

Some options of choosing energy adapters for this POE equipment.
1.please use a minimum of 18V energy adapter when the community cable size will not be extra than30 meters.
2.Please use a minimum of 24V energy adapter when the community cable size will not be greater than 50 meters.
3. The community cable is greater than 50 meters in size. It is suggested to make use of 48V-55V energy adapter.
4.In the event you decide the community cable in poor high quality,attempt your greatest to extend the enter voltage to make the facility provide system work usually,however don’t exceed DC55V.

Please be observed that there are following disadvantages of different 12V or 15V low voltage POE options:
1.The low voltage transmission within the community cable trigger voltage really equipped to the digicam to be too low as a result of massive resistance, leading to inadequate energy provide of the digicam, unstable operation, crash, and many others.
2.Because of the massive resistance of the low voltage on the community,the size of the community cable is usually restricted to much less 30meters.
3.The poor community cable high quality may cause the facility provide scarcity.

This POE swap Options:

• 9 x 10/100Mbps Auto-negotiation Quick Ethernet RJ-45 ports with 8-Ports PoE perform
• Swap Energy Hyperlink RJ45 Ethernet Ports Pin: Knowledge 1,2,3,6 , Energy +(4,5),-(7,8)
• Midspan Mode-B Unsolicited Energy(4,5+/7,8-)
• Helps 12~55V DC energy provide, Energy DC port 5.5 x 2.1mm,inside optimistic (+) outdoors damaging (-)
• Every port helps auto MDI/MDIX, so there is no such thing as a want to make use of cross-over cables.
• Full/half duplex switch mode for every port.
• Product Dimensions 125mm W x 68mm D x 32mm H

Notice: Gigabit (1000Mbps) ethernet system”for instance router” Please don’t entry “POE swap Energy Hyperlink port” this can harm your system.
Solely connecting to the router by way of the UpLink port

The DC Buck passive PoE Splitter. with following perform:
1,Switch the information sign enter from RJ45 socket 1236pins by way of the opposite aspect RJ45 connector to the IP digicam.
2,Transfering the DC18-60V energy enter from RJ45 socket 4578pins(45+, 78-) which the voltage will probably be lowered to 12V,then via the opposite aspect DC port(5.5 x 2.1 mm) into the IP digicam.

Enter / Output Specs :
DC Enter Voltage Max 60V DC
DC Enter Voltage Min 18V DC
DC Output Voltage 12V DC
Max Output Present 1.3A Max.
Energy Output DC Jack 5.5mm x 2.1mm

RJ45 Knowledge PIN: 1/2 & 3/6
RJ45 Energy PIN: 4/5+ & 7/8-

Ethernet Knowledge fee 10/100 Mbp
Ethernet Cable TIA/EIA 568 Cat.5
Ethernet Cable Connector RJ-45

Ge neral Specs:
Working Temperature -10oC ~ +60oC
Storage Temperature -20oC ~ +70oC
Humidity As much as 90%
Weight 58 g
Size: 240mm complete size (together with connectors),Excessive-quality oxygen-free copper Cable

Merchandise Included:

DC18-60V to 12V DC Buck Passive PoE Splitter Cable(with Waterproof accent) x8

DSLRKIT MID8P1U 9pots 8PoE Passive PoE swap x1
(Energy provide not included)
