Nanovna Testboard Package Community Evaluation Take a look at Demo Board Appropriate with DIP Shortly Assemble a Easy RF Circuit and Consider Efficiency on The NanoVNA
$12.99
Worth: $33.98 - $12.99
(as of Jul 08,2022 15:01:00 UTC – Particulars)
Package deal Record
1x Testboard Printed Circuit Board(Appropriate with DIP pads of VNWA Testboard and add 0805 and 1206 STM pads)
6x SMA Finish Connectors (similar kind as in NanoVNA)
4x Copper 8mm spacers
4x M2.5 4mm screws
2x 40 pin feminine SIL Socket
2x 40 pin feminine SIL Socket
Package deal Dimensions : 4 x 3.7 x 1.4 inches; 3.21 Ounces
Date First Obtainable : March 19, 2020
Producer : AURSINC
ASIN : B08642VPJX
The Testboard equipment permits NanoVNA customers to assemble a helpful Part jig to shortly assemble a easy RF circuit and consider their efficiency on the NanoVNA.
This check board accommodates a plug-in check circuit appropriate for VNWA Testboard, and a set of 0805 and 1206 patch check circuits are added.
This check board equipment is used for NanoVNA or different vector community analyzer user-friendly measurement plug-ins and SMT gadgets.
Product come unassembled, it’s worthwhile to assemble in keeping with your function. Please put together your individual welding instruments and construct a check circuit in keeping with your check wants. We’re not answerable for circuit steering.
Package deal embody: 1x Testboard Printed Circuit Board(Appropriate with DIP pads of VNWA Testboard and add 0805 and 1206 STM pads), 6x SMA Finish Connectors (similar kind as in NanoVNA), 4x Copper 8mm spacers, 4x M2.5 4mm screws,2x 40 pin feminine SIL Socket,2x 40 pin feminine SIL Socket
