OSTENT GSM Modem with Wavecom Q2303A Module COM/RS232/Serial Port at Instructions SMS Voice Name AU Plug Energy Adapter

Value: $37.79
(as of Jul 10,2022 11:16:01 UTC – Particulars)

Earlier than taking this merchandise, please verify whether or not your area is roofed by anybody of GSM 900MHZ/1800MHZ.

GSM Modem Product Listing
The entire product contains following checklist of articles:
1. One Energy Provide Adapter(AU plug), 7.5V 1A
2. One Information Line (COM: DB9 to DB15, 150cm extension wire).
3. One DB Antenna, 80mm
4. Modem Physique: white aluminous shell
5. One Sliding SIM Card Slot

Technical Parameters Specification for GSM Modem
1. Sort
GSM Modem with industrial-grade Wavecom Q2303A module.
2. Technological Specs
*Assist twin frequency: GSM 900/1800MHz
*Conform to ETSI GSM 2+ customary
*Output Energy:
Class4 (2W @ 900 MHz)
Class5 (1W @ 1800 MHz)
*Energy Supply: 5-24V DC
*Temperature Vary:
-20 Centigrade Diploma ~ +55 Centigrade Diploma lively standing
-25 Centigrade Diploma ~ +70 Centigrade Diploma preserved situation
*Product Measurement: customary
3. Primary Options
*Asynchronous, Clear or Non-transparent, The best baud price: 14400bits/s
*Serial Baud Charge: 300-115200bits/s
*Computerized Baud Charge: from 2,400 to 19,200bits/s
*Assist Group 3 Doc Facsimile Transmission
*Assist Switching between Voice and Fax
*V.42,V.42bis
*RS-232 Interface, Mini DB-9 Connector
*Management by way of AT Instructions (GSM 07.07, 07.05)
Voice, SMS Perform
*Voice Perform
Name
Pressing phone
Speech coding and decoding: full price, enhanced full price and half price
Double tone, a number of frequency (DTMF)
*SMS Perform
Writing and PDU
Level-to-point (MT/MO)
Cell broadcast
Industrial-Grade GSM Modem
Primarily based on Wavecom Q2303A Module
COM/RS232/Serial Port Interface
Management by way of AT Instructions
Assist Twin Frequencies: GSM 900/1800MHz
