POE extender 1 enter 2 output 10/100/1000M lively POE 802.3af/at or passive 48V compliant

Mannequin

EXT102GAF

Product

2 Port Gigabit PoE Community Extender

PoE Enter Port

Helps 1/2(+)，3/6(-)；4/5(+)，7/8(-)

MAX Enter Energy 30W(Non-compulsory 65W)

PoE Output Port

Helps IEEE802.3af/at

MAX Output Power30W

Dc in

1：Default:No Energy

2：Non-compulsory 12V 0.5A as community extender

3：Non-compulsory 52V 0.5A energy can be utilized as single port PoE Change

Watt

Standby Energy Consumption：≤3W；

Full-load Energy Consumption：≤30W；

Fastened Community Port

1*PoE Enter port，10/100/1000M Rj45

2*PoE Output port，10/100/1000M Rj45

DC In

As Community Extender： DC9-57V MAX 0.5A

As PoE Community Extender：DC37-57V MAX 0.5A

Operate

EXT(Port Isolation)

LED Indicator

Pwr:Energy LED

Port：（Inexperienced=Hyperlink LED+Orange=PoE LED）

ON/OFF:（ EXTFunction LED）

Hyperlink:(Hyperlink LED=10/100M Hyperlink、1000M=Gigabit Hyperlink)

Community Protocol

IEEE 802.3

IEEE 802.3i 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3ab1000BASE-T

IEEE 802.3x

IEEE 802.3af/at

Transmission Mode

Retailer and Ahead(full wirespeed)

Bandwidth

1Gbps

Packet Forwarding

7.2Mpps

MAC Handle

2K

Buffer

2.5M

Transmission Distance

10BASE-T ： Cat3,4,5 UTP(≤250 meter)

100BASE-TX ： Cat5 or later UTP(150 meter)

1000BASE-TX ： Cat6 or later UTP(150 meter)

Working Temperature/Humidity

-10～+55°C；5%～90% RH Non coagulation

Storage Temperature/Humidity

-40～+75°C；5%～95% RH Non coagulation

Product dimension/Packing dimension（L*W*H）

70mm*85mm*25mm

105mm*105mm*63mm

N.W/G.W（kg）

0.15kg/0.2kg

Set up

Desktop

Lightning safety degree

3KV 8/20us；

IP30

Certificates

CE mark, industrial；CE/LVD EN60950；
FCC Half 15 Class B；RoHS；

Guarantee

Entire machine for 1 yr(Equipment not included)
